External diameter
20 [mm]
Height
25 [mm]
Thread type
internal, 2 x M6
Maximal hoisting capacity
26 [kg]
Coating
Zinc (Zn)
Maximum working temperature
≤ 80 [°C]
Housing
mosiężna
Weight
60,5 [g]
Performance parameters
This magnet in housing is circular, cylindrical, shaped like a cylinder or disc.
Holding magnets are simple magnetic circuits composited of a magnet and a brass housing.
The magnet is glued into a brass housing, so it is more protected against impacts. There is an internal thread in the housing for attaching hooks or eye bolts. Direction of magnetization along the height. Due to the casing, the magnet is single-sided.
The brass housing increases its resistance to corrosion. It has been manufactured to excellent dimensional tolerances.
The maximum operating temperature is no more than 80 degrees Celsius. Neodymium magnets stick to metal surface.
You can attached magnet to surfaces made of ferromagnetic materials.
