Length
15 [mm] +0,1/-0,1
Width
8 [mm] +0,1/-0,1
Height
1 [mm] +0,1/-0,1
Grade
N38
Magnet type
Neodymium
Maximal hoisting capacity
0,63 [kg]
Magnetic field in geometrical center of the magnetic pole surface
0,08 [T]
Coating
NiCuNi with 3M 467MP adhesive
adhesive
yes
Weight
0,9 [g]
Performance parameters
The magnetic force value given above, expressed in kilograms, was measured under ideal conditions. A thick iron plate with a smooth, unpainted surface was used. The force required to detach the magnet from the plate was perpendicular to the plate.
do not use in water
Sintered neodymium magnets are brittle (fragile). A neodymium magnet without housing could break after an impact with another strong magnet.
The magnet parameter values presented here are the result of measurements taken on one specific magnet and are used to compare magnets available in the online shop. We recommend testing the magnet yourself under the expected operating conditions.
Physical properties
Density |
~7,5 [g/cm3] |
Vickers’ hardness (HV) |
~600 [kg/mm2] |
Resistivity |
~144 [uOhm x cm] |
If you require neodymium magnets manufactured to strict specifications, please send us your enquiry along with your requirements.
15x8x1/N38 - Neodymium magnet
This is a thin block magnet. It is rectangular in shape.
It is a neodymium magnet, magnetised along the height. It has an excellent adhesive layer 3M or adhesive foam 3M. It is very easy to stick after removing the protective tape. This magnet is very easy to stick to many surfaces. It has been protected against corrosion by nickel plating. It has been manufactured accordnig to excellent dimensional tolerances. The maximum operating temperature is no more than 80 degrees Celsius. Neodymium magnets stick to metal surface. This magnet is strong for its dimensions.
MPL15X8X1N38_3M467MP
2877 Items
